AYA FASTENRS ka gafe|Mun na i be se ka baara kɛ ni Counterink Head Machine sɛrɛ ye?

Konteterinki kungolo masin nɛgɛw, minw be weele fana ko kungolo pɛtɛ pɛtɛninw, olu be sanfɛla- ɲumanya fɛnw cɛma walima bolokuruw cɛma minw be sɔrɔ sugu la. O fɛnw suguw be yɛlɛma yɛlɛma mekaniki ni baarakɛyɔrɔ sifa wɛrɛw la.
O faniw dilanna kɛrɛnkɛrɛnnin na ka lafiɲɛ cogo dɔ la walisa ka lafiɲɛ ni fɛɛn wala yɔrɔ min na u be don. I be se ka kabakoya k’a lɔn ko o visiw be weele ko nɛgɛw minw be se ka yɛlɛma sabu u be se ka jigi ni fɛɛnw wala yɔrɔw ye.

N’i ​​be Countersunk Head Machine Screws boli ka don fɛɛn dɔ la wala yɔrɔ dɔ la, kungolo bena jigi walisa o nɛgɛw ka se ka nɔgɔ ni fɛɛn minw donna u kɔnɔ. O be kɛ sabu a be ni kungolo pɛtɛnin dɔ ye min be sanfɛ.
Countersunk Head Machine Screws be lɔn u kuun pɛtɛnin fɛ, k’u danfara ka bɔ ɲɔgɔn na ni visi wɛrɛw ye sugu la.



















A bonya d		M1	M1.2	M1.4	M1.6	M2	M2.5	M3	(M3.5)	M4
P	Karafu	0.25	0.25	0.3	0.35	0.4	0.45	0.5	0.6	0.7
a	max	0.5	0.5	0.6	0.7	0.8	0.9	1	1.2	1.4
dk	max=nominal bonya	1.9	2.3	2.6	3	3.8	4.7	5.6	6.5	7.5
	lajɛ	1.76	2.06	2.46	2.86	3.5	4.4	5.3	6.14	7.14
k	max	0.6	0.72	0.84	0.96	1.2	1.5	1.65	1.93	2.2
n	max	0.45	0.5	0.5	0.6	0.7	0.8	1	1	1.2
	lajɛ	0.31	0.36	0.36	0.46	0.56	0.66	0.86	0.86	1.06
r	max	0.1	0.12	0.14	0.16	0.2	0.25	0.3	0.35	0.4
t	max	0.3	0.35	0.4	0.45	0.6	0.7	0.85	1	1.1
	lajɛ	0.2	0.25	0.28	0.32	0.4	0.5	0.6	0.7	0.8
x	max	-	-	-	0.9	1	1.1	1.25	1.5	1.75

A bonya d		M5	M6	M8	M10	M12	(M14)	M16	(M18)	M20
P	Karafu	0.8	1	1.25	1.5	1.75	2	2	2.5	2.5
a	max	1.6	2	2.5	3	3.5	4	4	5	5
dk	max=nominal bonya	9.2	11	14.5	18	22	25	29	33	36
	lajɛ	8.84	10.57	14.07	17.57	21.48	24.48	28.48	32.38	35.38
k	max	2.5	3	4	5	6	7	8	9	10
n	max	1.51	1.91	2.31	2.81	3.31	3.31	4.37	4.37	5.37
	lajɛ	1.26	1.66	2.06	2.56	3.06	3.06	4.07	4.07	5.07
r	max	0.5	0.6	0.8	1	1.2	1.4	1.6	1.8	2
t	max	1.3	1.6	2.1	2.6	3	3.5	4	4.5	5
	lajɛ	1	1.2	1.6	2	2.4	2.8	3.2	3.6	4
x	max	2	2.5	3.2	3.8	4.4	5	5	6.3	6.3
1, Minɛnw. a)Steel, Sɛbte kalan (kaso): 4,8,5,8,8.8. DIN ISO 898-1 b) Nɛgɛ min tɛ se ka yɛlɛma, a be se ka yɛlɛma (kɔnɔna): A2-70, A4-70. DIN 267-11 c)Non-feran nɛgɛ, Fanga kilasi (fɛn): CuZn=copper zɛnki, CU2 walima CU3 ka kɛɲɛ ni dilanbaga ka sugandili ye. DIN 267-18 d)Fali wɛrɛw wala minanw wala fɛɛn dɔ, i n’a fɔ CU3, ka kɛɲɛ ni bɛnkan ye .





Tiɲɛ na, Counteronsunk Head Machine Screws be na ni dilanfɛnw ye minw be mɔgɔ lasun ani fɛn wɛrɛw minw b’a to u be sanfɛ-choice diɲɛ bɛɛ kɔnɔ. O la, a be se ka kɛ ko mɔgɔw be ɲɔgɔn sɔsɔra ko:

●Sturdiness - Counterensunk Head Machine Screws ka ca a la, u be lɔ ni fɛɛn barikaman dɔ ye, i n’a fɔ nɛgɛ min tɛ yɛlɛma, o b’a to u be sabati ani ka fanga sɔrɔ.
● Fangaba - Counterensunk Head Machine Screws be na ni fangaba ye min b’a to u be kɛ sugandili ɲuman ye ka baara kɛ n’u ye.
●Dimensiyɔn - A be na ni dimensiyɔn cogoya tigitigiw ye minw be dɛmɛ don ka jigi laban.

O ye misaliya damadɔ ye minw be sɔrɔ Countensunk Head Machine Screws ka koow la. I bena fɛɛn wɛrɛw fana sɔrɔ minw tɛ se ka sɛbɛ barokun kelen kɔnɔ.





I be se ka nafa sɔrɔ nafa minw tɛ se ka jati, n’i be Countersunk Head Machine Screws sugandi i makoya kama. O Screws ka nafaw kɛra sababu ye k’o visiw ɲini. O la, a be se ka kɛ ko nafa minw be sɔrɔ Countersunk Head Machine Screws la:

●Counteronsunk Head Machine Screws b’a to a ka nɔgɔ ka boli fɛɛn wala dugukolo kan.
● Counteronsunk Head Machine Screws be yɔrɔ fila wala fɛɛn fila cɛ.
●Kontɛriw kuntigi Machine Screws be yiri ka tilenninya mara.
● Kontɛriw ka kuntigi Machine Screws be yɔrɔw bali minw be yɛlɛma ani u be kungolow kɔrɔta. O kɔrɔ ko o visiw be jaabi ɲumanw di.
●A b’a to i be se ka baara kɛ ni pɔɔti wala fani ye walisa ka visi kuun datugu ani ka yecogo dɔ dilan min saniyanin tɛ.

I be se k’a miiri ko nin ye laban ye, nka Countersunk Head Machine Screws be na ni nafa caaman ye. An ye o visiw ka nafaw dɔrɔn lo sɛbɛ.





Countersunk Head Machine Screws dilanna walisa ka baara sifa caaman kɛ. U be se fana ka bɛn ni makoya bɛɛ wala makoɲɛfɛn bɛɛ ye. O la, a be se ka kɛ ko mɔgɔw be ɲɔgɔn sɔsɔra ko:

●Fɛɛn fila wala fɛɛn dɔ yɔrɔ minw ka teli ka kɛ.
● Ka daaw sɔrɔ n’i be yɔrɔ dɔ labɛn, o b’a to daaw ni kadriw be ɲɔgɔn sɔrɔ cogo nɔgɔman na.
●Yiriwali wɛrɛw ani farali sɛbɛw.

Ka fara o misaliyaw kan, Countersunk Head Machine Screws be se ka baara kɛ kuun caaman kama sabu u be se ka kungolo sutura pewu duguma.
